INFINITY MIRROR ARGB FAN Series

Infinity Mirror ARGB Design

Stunning mirror effect at the fan center for a mesmerizing RGB glow.

Translucent Fan Blades

Amplifies RGB lighting for a more immersive visual experience.

Optional PWM Support

Gives gamers precise control over fan speed and cooling performance.

Anti-Vibration Pads

Reduces noise and absorbs vibration for smoother operation.

Low Noise, High RPM

Engineered for quiet performance even at high speeds.

Type A

dimensions

120x120x25mm

bearing time

Hydraulic Bearing

fan speed

800-1600 ± 10%RPM

airflow

42.9 CFM

Air pressure

1.6-2.04 mmH2O ± 10%

noise level

18.7-28.3 dBA

RATED VOLTAGE (FAN)

DC 12V

RATED CURRENT (FAN)

0.25A

RATED VOLTAGE (LED)

DC 5V

RATED CURRENT (LED)

0.3A

POWER CONSUMPTION

4.5W

FAN CONNECTOR

4-pin PWM

RGB CONNECTOR

5V 3-pin ARGB

LIFE

30000 Hrs

Type B

dimensions

120x120x25mm

bearing time

Hydraulic Bearing

fan speed

800-1600 ± 10%RPM

airflow

42.9 CFM

Air pressure

1.6-2.04 mmH2O ± 10%

noise level

18.7-28.3 dBA

RATED VOLTAGE (FAN)

DC 12V

RATED CURRENT (FAN)

0.25A

RATED VOLTAGE (LED)

DC 5V

RATED CURRENT (LED)

0.3A

POWER CONSUMPTION

4.5W

FAN CONNECTOR

4-pin PWM

RGB CONNECTOR

5V 3-pin ARGB

LIFE

30000 Hrs

Type C

dimensions

120x120x25mm

bearing time

Hydraulic Bearing

fan speed

800-1600 ± 10%RPM

airflow

42.9 CFM

Air pressure

1.6-2.04 mmH2O ± 10%

noise level

18.7-28.3 dBA

RATED VOLTAGE (FAN)

DC 12V

RATED CURRENT (FAN)

0.25A

RATED VOLTAGE (LED)

DC 5V

RATED CURRENT (LED)

0.3A

POWER CONSUMPTION

4.5W

FAN CONNECTOR

4-pin PWM

RGB CONNECTOR

5V 3-pin ARGB

LIFE

30000 Hrs
